Gunite Machine/ Shotcrete Machine/Spray Machine from China manufacturer

Product Detail

Model No.: PZ-9

Production Capacity: 200set per month

Delivery Date: after received the first pa...

Max. delivery: 150m

Air Consumption: 9-10m3/min

Voltage: 380v/440v/660v/1140v 50...

Means of Transport: Ocean

Packing: in veneer case

Out put: 9m3/h

Pressure: 0.2-0.6MPa

Power: 7.5kw electric /10ph diesel

1.Dry Shotcrete machine
2.Durable quality
3.CE certificate
4.Used for Pool, civil engineering slope stabilization, underground and so on.

Application:

Shotcreting for tunnels, hydro-power engineering, mines, underground engineering, civil engineering and slope stabilization, etc.
Artificial soil seeding for no soil surface, such as rock, sand, and for no fertility soil surface.
Refractory spraying and repair for industrial kilns or kilns' inner liner.

Features:

Non-adhesion going-through rotor with new material chamber, completely eliminate bonding and blocking during operation so as to reduce clearance and maintenance period.
Thin follow conveying method with vortex flow, so the spraying flow is even, continuous and steady, to improve the shotcrete quality.
Four-point clamping device make it easy to adjust the press between sealing plate and rotor disk so as to no air and dust leak and prolong consumption parts life.
Particularly used for dry, damp mix and steel (polymer) fibre reinforced shotcrete.
Three drive models: by Electric motor, air motor or diesel engine.
For the most specific risks of this machine, safety and compliance with the essential requirements of the Directive has been based on elements of EN ISO 12100-1:2003, EN ISO 12100-2:2003/A1:1995, EN 60204-1:2006 and EN 1050:1997.

PZ-9(electric driven)

Output Capacity:	9CBM/hour
Maximum Conveying Distance:	150m
Desired Shotcrete Ingredient Ratio:	Cement/sand and gravel < 0.35
Maximum Aggregate Size:	20mm
Inner Diameter of Conveying Hose:	64mm
Working Compressed Air Pressure:	0.2 ~ 0.6 MPa
Conveying Air Consumption:	9 ~ 10CBM / min)
Motor Power:	7.5KW
Dimensions:	1.5x0.9x1.3m
Net Weight:	900kg
